Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation protocol:
Hand-tighten until metal-to-metal contact, then apply 1/4 turn with wrench.
Always use backup wrench on hex base during installation. Maximum
recommended torque: 1.2 N·m. For plastic tubing, insert until 2mm
protrusion beyond sleeve collar.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC6-M5 Threaded Quick Connect Fitting Details
- Model: APC6-M5
- Type: Straight thread-to-tube quick connector
- Thread specification: M5×0.8 external thread (male)
- Material: Brass (nickel-plated) with PPS resin housing
- Operating pressure: 0.2-1.0 MPa
- Temperature range: -20℃ to 80℃
- Tube compatibility: 4mm OD (6mm sleeve compatible)
- Seal material: HNBR (Hydrogenated Nitrile) rubber
- Flow rate: 120 L/min (at 0.5 MPa)
- Leakage rate: <10 cm³/min under max pressure
- Vibration resistance: 10-2000 Hz (3G acceleration)
- Protection rating: IP40
- Weight: 8.5±0.3g
- Dimensions: 30mm(L) × 16mm(W) × 16mm(H)
High-flow pneumatic connector featuring one-touch tube release mechanism with positive lock. The 30° cone seat design ensures bubble-tight sealing even under pulsating pressure conditions. Nickel-plated brass construction resists oxidation in humid environments.
Typical Applications:
- Modular pneumatic test bench setups
- 3D printer filament cooling systems
- Medical device pneumatic circuits
- Robotic gripper air supply lines
- Semiconductor wafer handling equipment
Installation protocol:
Hand-tighten until metal-to-metal contact, then apply 1/4 turn with wrench.
Always use backup wrench on hex base during installation. Maximum
recommended torque: 1.2 N·m. For plastic tubing, insert until 2mm
protrusion beyond sleeve collar.
| Property | Property Value |
|---|---|
| sku | APC6-M5 |
| Insert Tube | <6mm> |
| Threaded Port | M5 |
