Airtac APC Threaded Quick Connect Coupling APC6-M6
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC6-M6 Threaded Quick Connector Specifications
- Model: APC6-M6
- Thread type: M6×1.0 external thread (ISO metric)
- Tube compatibility: 6mm OD pneumatic tubing (PU/Nylon)
- Max working pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile rubber)
- Flow rate: 350 NL/min @ 0.5 MPa
- Leakage: ≤0.1 NL/min under rated pressure
- Weight: 12.5g ±0.3g
- Dimensions: 25mm(L) × 16mm(W) × 16mm(H)
- Installation torque: 0.8-1.2 N·m
- IP rating: IP40 (dust protected)
High-flow push-to-connect fitting with precision-machined threads for leak-free transitions between metric threaded ports and soft pneumatic tubing. Features a dual-locking sleeve design for vibration resistance and one-hand operation. The 30° swivel capability prevents hose kinking during machine motion.
- Modular pneumatic circuit assembly lines
- CNC machine tool coolant control systems
- Robotic end-effector tool changers
- Semiconductor wafer handling equipment
- Mobile hydraulic test bench connections
Installation note:
Always deburr tubing ends before insertion. For M6 thread engagement,
apply 2-3 drops of LOCTITE 577 thread sealant (PTFE-free) and torque
using a calibrated hex-key wrench. Perform pressure tests at 1.5×
working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APC6-M6 |
| Insert Tube | <6mm> |
| Threaded Port | M6 |
