Airtac APC Threaded Quick Connect Coupling APC6-M8
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC6-M8 Technical Details
- Model Code: APC6-M8
- Thread Specification: M8×1.0 male thread (ISO 228-1 standard)
- Tube Compatibility: 6mm OD polyurethane/nylon tubing
- Body Material: Nickel-plated brass (core components) + POM (housing)
- Seal Material: HNBR (Hydrogenated Nitrile) O-rings
- Pressure Range: 0.3-1.5 MPa (43.5-217.5 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Installation Torque: 8-12 N·m (70.8-106.2 in-lb)
- Flow Rate: 300 NL/min at 0.5 MPa
- Leakage Rate: <3 bubbles/min under 0.5 MPa air pressure
- Weight: 18.5g ±0.5g
- Dimensions: 32mm(L) × 21mm(W) × 21mm(H)
- IP Rating: IP54 (dust protected & water splash resistant)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
High-flow push-to-connect fitting with 360° rotatable collar for flexible hose routing. Features dual-stage sealing with dust cap retention system. The chrome-plated brass insert prevents thread galling during installation. Compatible with pneumatic and low-pressure hydraulic systems (non-lubricated media).
- Robotic arm end effector connections
- CNC machine tool pneumatic circuits
- Food processing equipment (oil/fat resistant seals)
- Mobile hydraulic test bench setups
- Semiconductor cleanroom automation
- Electric vehicle battery cooling systems
Installation Protocol:
Apply 2-3 drops of silicone oil (ISO VG 10) on threads before assembly.
Use backup wrench on hex base during tightening. Perform pressure test
at 1.25× operating pressure for 5 minutes post-installation.
Avoid using with:- Phosphate ester hydraulic fluids
- Media containing solid particles >50μm
- Continuous exposure to UV radiation
| Property | Property Value |
|---|---|
| sku | APC6-M8 |
| Insert Tube | <6mm> |
| Threaded Port | M8 |
