Airtac APC Threaded Quick Connect Coupling APC6-M8X1
$2.80
Regular price
$10.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC6-M8X1
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation protocol:
Apply silicone-free lubricant to tube end before insertion.
Engage thread with 1.2-1.5 N·m torque using 12mm wrench.
Perform monthly leak checks using soap bubble test.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC6-M8X1 Technical Details
- Model Code: APC6-M8X1
- Thread Specification: M8×1 male thread (ISO 228-1)
- Tube Compatibility: Ø6mm OD pneumatic tubing
- Material: Nickel-plated brass body + PPS resin sleeve
- Seal Type: Double O-ring (NBR rubber)
- Max Working Pressure: 1.5 MPa (217 psi)
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Flow Rate: 300 NL/min @ 0.5 MPa
- Insertion Force: ≤25 N (with lubrication)
- Pull-out Resistance: ≥70 N (tube retention)
- Weight: 18.5g ±0.5g
- Dimensions: 32mm(L) × 12mm(Dia) × 19mm(Hex)
- IP Rating: IP40 (non-submerged environments)
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
High-flow push-to-connect fitting with integrated thread locking collar, featuring 360° rotatable sleeve for flexible hose orientation. Precision-machined lead-in chamfer prevents tube scoring during installation. Compatible with PU, nylon, and rubber tubing (shore hardness 80A-95A).
Implementation Scenarios:
- Robotic arm pneumatic gripper circuits
- CNC machine tool coolant line quick-disconnect
- Food packaging machine air knife connections
- Semiconductor wafer handling vacuum/pressure switches
- Electric vehicle battery cooling system test rigs
Installation protocol:
Apply silicone-free lubricant to tube end before insertion.
Engage thread with 1.2-1.5 N·m torque using 12mm wrench.
Perform monthly leak checks using soap bubble test.
| Property | Property Value |
|---|---|
| sku | APC6-M8X1 |
| Insert Tube | <6mm> |
| Threaded Port | M8×1 |
