Airtac APC Threaded Quick Connect Coupling APC6-M8X1.25
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC6-M8X1.25 Threaded Quick Connector Specifications
- Model: APC6-M8X1.25
- Type: Push-to-connect pneumatic fitting with male metric thread
- Thread specification: M8×1.25 external thread (ISO 261)
- Tube compatibility: 6mm OD (outer diameter) pneumatic tubing
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Operating pressure: 0-1.0 MPa (0-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Max flow rate: 350 L/min (at 0.5 MPa)
- Thread torque resistance: ≤25 N·m
- Vibration resistance: ≤2.5mm amplitude at 10-60Hz
- Weight: 14.5g ±0.3g
- Dimensions: 32mm(L) × 12mm(D) × 12mm(W)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
A corrosion-resistant quick-connect fitting designed for rapid assembly in pneumatic systems. Features a 30° push-button release angle for tool-free tube insertion/removal. The tapered thread design ensures airtight sealing even in high-vibration environments. Compatible with ISO 8434-1 standard tubing.
- Robotic arm pneumatic circuits
- CNC machine tool air supply lines
- Packaging machine actuator connections
- Laboratory pneumatic control systems
- Food processing equipment (dry air applications)
Installation note:
Cut tubing square and deburr before insertion. For optimal sealing,
insert tube until it bottoms out (audible click). Maximum permissible
lateral tubing load: 15N. Not recommended for hydraulic fluids.
| Property | Property Value |
|---|---|
| sku | APC6-M8X1.25 |
| Insert Tube | <6mm> |
| Threaded Port | M8×1.25 |
