Airtac APCF Female Thread Straight Connector APCF12-M16
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF Series Female Thread Straight Fitting APCF12-M16 Technical Details
- Model Code: APCF12-M16
- Thread Specification: M16×1.5 internal thread (ISO 1179-1 standard)
- Material: Lead-free brass CW617N (nickel-plated surface)
- Seal Material: HNBR (Hydrogenated Nitrile) with PTFE backup ring
- Pressure Rating: 0.3-1.6 MPa (43-232 psi)
- Temperature Range: -20℃ to 150℃ (continuous operation at 80℃ max)
- Port Connection: G1/8 BSPP parallel thread equivalent
- Flow Coefficient (Cv): 0.45
- Proof Pressure: 2.4 MPa
- Burst Pressure: 4.8 MPa
- Weight: 48g ±2g
- Dimensions: 32mm (L) × 16mm (W) × 16mm (H)
- Surface Roughness: Ra ≤3.2μm at sealing surfaces
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant, REACH SVHC-free
Precision-machined connector featuring dual-stage sealing (radial + axial) for leak-free performance in high-vibration environments. The electroless nickel plating provides corrosion resistance against water glycol and mild chemicals. Optimized flow path reduces turbulence by 18% compared to standard fittings.
- Pneumatic cylinder manifolds requiring compact routing
- Robotic end-effector tooling with space constraints
- High-cycle automation equipment (1M+ cycles rating)
- Mobile hydraulic systems with thermal cycling demands
- Cleanroom-compatible machinery (ISO Class 5 environments)
Installation Protocol:
Apply 2-3 wraps of PTFE tape clockwise (viewed from port end).
Torque to 14-16 N·m using flank-contact wrench. Pressure test
at 1.25× system pressure for 10 minutes post-installation.
| Property | Property Value |
|---|---|
| sku | APCF12-M16 |
