Airtac APCF Female Thread Straight Connector APCF12-M20
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF12-M20 Female Threaded Straight Connector Specifications
- Model: APCF12-M20
- Type: Female-to-female straight thread adapter
- Thread specification: M20×1.5 internal threads (both ends)
- Material: Brass with nickel plating (CuZn39Pb3)
- Seal material: NBR (standard) / FKM optional
- Working pressure: 0.2-1.5 MPa (29-218 PSI)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Installation torque: 35-45 N·m
- Surface hardness: HV0.3 130-250
- Corrosion resistance: 96hrs neutral salt spray test passed
- Weight: 182g ±3%
- Dimensions: 58mm(Length) × 32mm(Width) × 32mm(Height)
- Flow coefficient (Cv): 2.8
- Protection rating: IP54 (as per IEC 60529)
A precision-machined connector featuring dual internal metric threads with 360° sealing surface design. The electroless nickel plating provides enhanced corrosion resistance against water vapor and mild chemicals. Optimized internal flow path reduces turbulence by 18% compared to standard adapters.
- High-pressure pneumatic line transitions in packaging machinery
- Compressed air distribution systems (ISO 8573-1:2010 Class 2 compliant)
- Tool changer interfaces for CNC machine pneumatics
- Hydraulic sensor mounting in automotive assembly lines
- Vacuum system plumbing for semiconductor handling equipment
Installation protocol:
Use torque wrench with 19mm hex socket. Apply thread sealant only on male threads,
avoiding contamination of the first two thread pitches. Maximum re-torque cycles: 5 times.
- Sealant: LOCTITE 577 (for permanent installations)
- Thread protectors: ATP-20M (sold separately)
- Adapter kits for BSPP/BSPT threads: AK-M20 series
