Airtac APCF Female Thread Straight Connector APCF4-M5
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APCF4-M5
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Available in multiple models/specifications for wide application across pneumatic systems;
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
Installation protocol:
Use two wrenches during assembly - one to hold the base fitting and another to tighten.
Apply thread sealant only on male threads, avoiding contact with the sealing surface.
Maximum angular deviation: ≤3° from axis after installation.
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF4-M5 Female Thread Straight Fitting Detailed Specifications
- Model: APCF4-M5
- Type: Female thread x Tube straight connector
- Thread Standard: Metric (M5×0.8 internal thread)
- Applicable Tube OD: 4mm (for PU/Nylon tubing)
- Material: Nickel-plated brass (C3604 lead-free)
- Working Pressure: 0.05-1.6 MPa
- Temperature Range: -20℃ to +80℃
- Seal Material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Surface Treatment: Electroless nickel plating (5-8μm thickness)
- Proof Pressure: 2.4 MPa
- Burst Pressure: ≥4.8 MPa
- Weight: 8.2g ±0.3g
- Dimensions: 18mm(Total Length) × 10mm(Hex Width) × 8mm(Thread End Diameter)
- Installation Torque: 0.5-0.7 N·m (recommended with thread seal tape)
- Vibration Resistance: 10-2000Hz, 1.5mm amplitude
Precision-machined pneumatic connector featuring leak-proof double-seal structure (O-ring + metal-to-metal contact). The hexagonal body design allows tool-assisted tightening in confined spaces. Nickel plating provides corrosion resistance in humid environments.
Typical Applications:
- Miniature pneumatic circuit branching in robotics
- Sensor air supply connections on SMT equipment
- Medical device gas line interfaces
- 3D printer pneumatic extruder connections
- Laboratory analytical instrument plumbing
Installation protocol:
Use two wrenches during assembly - one to hold the base fitting and another to tighten.
Apply thread sealant only on male threads, avoiding contact with the sealing surface.
Maximum angular deviation: ≤3° from axis after installation.
Compatibility Note:
Compatible with ISO 1179-2 standard ports. Not recommended for use with
PTFE tubing or in environments with phosphate ester-based lubricants.
Annual seal replacement suggested for continuous operation systems.
| Property | Property Value |
|---|---|
| sku | APCF4-M5 |
