Airtac APD T-Side Port Tee Fitting APD10-01
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Joint APD10-01 Technical Specifications
- Model: APD10-01
- Type: T-shaped 3-way connector (Lateral port configuration)
- Thread standard: Metric (M5×0.8)
- Material: Brass body with nickel plating
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.05-1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range:
- Operation: -20℃ to 80℃
- Storage: -30℃ to 90℃
- Weight: 35g ±1g
- Dimensions: 18mm(L) × 18mm(W) × 24mm(H)
- Surface roughness: Ra ≤3.2μm
- Port configuration: 3-way right-angle flow path
- Compliance: RoHS 2.0 compliant
Precision-engineered tee connector featuring a compact lateral port design for space-constrained pneumatic systems. The nickel-plated brass construction ensures corrosion resistance while maintaining 500,000+ cycle durability. Optimized internal flow channels minimize pressure drop (ΔP ≤0.02MPa @ 0.5MPa).
- Branch line connections in automated assembly lines
- Pneumatic tool air distribution networks
- Medical device gas control systems
- Packaging machine actuator circuits
- Laboratory instrumentation air supply splits
Installation guidelines:
Apply 2-3Nm torque during assembly. Use thread sealant only on male threads.
Align flow arrows with system direction. Test at 0.8MPa for 5 minutes post-installation.
- Compressed air (ISO 8573-1:2010 Class 2-4-2 recommended)
- Inert gases (N₂, CO₂)
- Not suitable for oxygen systems or hydrocarbon fluids
| Property | Property Value |
|---|---|
| sku | APD10-01 |
