Airtac APD T-Side Port Tee Fitting APD10-03
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD10-03 Side Port T-Connector Specifications
- Model: APD10-03
- Type: T-shaped side port connector (push-in fitting)
- Thread standard: Metric (M5×0.8) / Optional NPT1/8
- Tube OD compatibility: Ø4mm (1/8") pneumatic tubing
- Material: Brass with nickel plating (stainless steel variant available)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile) rubber standard, FKM optional
- Weight: 12.5g ±0.3g
- Dimensions: 20mm(L) × 15mm(W) × 15mm(H)
- Port configuration: 3-way (1 inlet, 2 outlets at 90°)
- Flow coefficient (Cv): 0.15
- Vibration resistance: ≤10Hz @ 2.5mm amplitude
Precision-engineered T-connector featuring tool-free tube insertion and 360° rotatable ports for flexible piping layouts. The chamfered edge design prevents tubing abrasion during installation. Rated for 500,000+ insertion cycles with leak-proof performance under dynamic pressure fluctuations.
- Branching pneumatic circuits in CNC machine tooling
- Modular pneumatic control systems for semiconductor handling
- Air distribution in automated packaging lines
- Medical device pneumatic manifolds
- Robotic arm end-effector air supply networks
Installation protocol:
Insert tubing until audible click (minimum insertion depth 10mm).
For maintenance, depress stainless steel release collar while pulling tubing.
Apply silicone-free lubricant when using FKM seals in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | APD10-03 |
