Airtac APD T-Side Port Tee Fitting APD14-03
$10.04
Regular price
$17.54
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD14-03
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation guidelines:
Apply 2-3Nm torque during assembly. Use thread sealant only on male threads.
For gas applications, orient the tee vertically with flow direction arrow pointing upward
to prevent liquid accumulation. Maximum recommended cyclic rate: 500,000 connections.
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Joint APD14-03 Technical Specifications
- Model: APD14-03
- Type: T-shaped 3-way connector (equal tee)
- Thread standard: Metric (M5×0.8) & BSPP options
- Material: Lead-free brass (C37700) with electroless nickel plating
- Seal material: NBR (Nitrile) O-rings
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃ (continuous use)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Flow coefficient (Cv): 0.22
- Weight: 18.5±0.3g
- Dimensions: 24mm (L) × 24mm (W) × 28mm (H)
- Surface roughness: Ra0.8μm (internal passages)
- Vibration resistance: 10-2000Hz, 20G acceleration
Precision-machined tee connector featuring triple sealing structure with 360° rotatable ports. The internal flow path uses CFD-optimized geometry to minimize pressure drop (ΔP ≤0.02MPa @1MPa). Compatible with ISO 15407-1 standards for pneumatic systems.
Typical Applications:
- Branch line connections in pneumatic manifolds
- Vacuum system instrumentation clusters
- Modular pneumatic training kits
- Industrial robot end effector plumbing
- Compressed air sampling points
- Medical gas distribution systems
Installation guidelines:
Apply 2-3Nm torque during assembly. Use thread sealant only on male threads.
For gas applications, orient the tee vertically with flow direction arrow pointing upward
to prevent liquid accumulation. Maximum recommended cyclic rate: 500,000 connections.
| Property | Property Value |
|---|---|
| sku | APD14-03 |
