Airtac APD T-Side Port Tee Fitting APD4-02
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Fitting APD4-02 Technical Details
- Model: APD4-02
- Type: T-shaped push-in pneumatic tee connector
- Material: Brass with nickel-plated surface
- Thread standard: PT1/8 (BSPP)
- Operating pressure: 0.2–1.0 MPa
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Tube compatibility: Ø4mm pneumatic tubing
- Weight: 12g ±0.5g
- Dimensions: 20mm(L) × 15mm(W) × 15mm(H)
- Port configuration: 3-way equal diameter
- Max flow rate: 350 NL/min
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP40
- Certification: RoHS compliant
Precision-engineered tee connector featuring a corrosion-resistant nickel-plated brass body and ergonomic push-to-connect design. The 120° angled ports enable compact plumbing configurations while maintaining laminar airflow. Includes integrated O-ring seals with dust caps for unused ports.
- Branching pneumatic circuits in automation equipment
- Air distribution in packaging machine tooling
- Medical device gas line splitting
- Laboratory instrument pneumatic networks
- Robotic end-effector air supply systems
Installation guidelines:
Cut tubing ends square and deburr before insertion. For optimal seal integrity,
insert tubes until they contact the internal stop (audible click). Rotate fittings
during maintenance rather than pulling tubes directly. Maximum recommended
tightening torque: 1.2N·m.
| Property | Property Value |
|---|---|
| sku | APD4-02 |
