Airtac APD T-Side Port Tee Fitting APD4-M10
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD4-M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation protocol:
Apply 32-38 N·m torque during assembly. Use thread sealant only on male ports.
For vertical mounting, orient side port within ±15° of horizontal plane to prevent seal deformation.
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Port Side Tee Connector APD4-M10 Technical Details
- Model: APD4-M10
- Type: T-port side entry tee connector (metal-body)
- Thread standard: Metric (M)
- Port size: M10×1.0 (ISO 6149-compliant)
- Material: Anodized aluminum alloy (AL6063-T5)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) rubber
- Surface treatment: Clear anodized (8-12μm thickness)
- Weight: 38g ±2g
- Dimensions: 34mm(L) × 28mm(W) × 28mm(H)
- Flow coefficient (Cv): 0.45
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, ISO 9001 manufactured
Heavy-duty T-style pneumatic connector featuring 360° rotatable side port for flexible piping layouts. The precision-machined threads ensure leak-free connections in high-vibration environments. Nickel-plated brass inserts prevent galling during repeated installations.
Industrial Applications:
- Modular pneumatic circuit branching in automation cells
- Compressed air distribution in packaging machinery
- Tooling air supply connections for CNC equipment
- Robotic end-effector pneumatic networks
- Plastic injection molding machine air circuits
Installation protocol:
Apply 32-38 N·m torque during assembly. Use thread sealant only on male ports.
For vertical mounting, orient side port within ±15° of horizontal plane to prevent seal deformation.
Fluid compatibility:
Compressed air (ISO 8573-1 Class 3.4.2), inert gases. Not recommended for steam,
aggressive chemicals, or petroleum-based fluids exceeding 40℃.
| Property | Property Value |
|---|---|
| sku | APD4-M10 |
