Airtac APH Hex Head Connector APH12-M20
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Series Hexagon Connector APH12-M20 Technical Details
- Full Model Number: APH12-M20
- Thread Specification: M20×1.5 (Metric Fine Thread)
- Body Material: Lead-Free Brass CW617N
- Surface Treatment: Electroless Nickel Plating (5-8μm)
- Seal Material: HNBR (Hydrogenated Nitrile) O-Ring
- Pressure Range: 0.05-1.2 MPa (7-174 PSI)
- Temperature Range: -30℃ to 120℃ (Static), -10℃ to 80℃ (Dynamic)
- Port Connection: G1/4 Female Thread (ISO 228-1)
- Tightening Torque: 35-40 N·m (25.8-29.5 lb-ft)
- Hex Size: 19mm Across Flats
- Weight: 48g ±2g (with packaging: 55g)
- Dimensions: 38mm(Length) × 19mm(Hex Width) × 22mm(Max OD)
- Compatible Tubing: Ø12mm Polyurethane/Nylon (Push-in Type)
- Certifications: RoHS 2.0, REACH SVHC, ISO 9001:2015
Precision-machined hexagon connector featuring triple-sealing technology with primary thread seal, secondary O-ring compression, and tertiary metal-to-metal contact. The 45° inverted flare seat design prevents tube slippage under vibration. Nickel plating provides >500hr salt spray resistance (ASTM B117).
- Pneumatic cylinder port connections in assembly robots
- Modular manifold systems for packaging machinery
- High-cycle automation equipment requiring vibration resistance
- Hydraulic test bench instrumentation (low-pressure lines)
- Semiconductor fab gas delivery systems (non-corrosive media)
Installation Protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads. Hand-tighten plus 1.25-1.75 turns with wrench.
Maximum angular misalignment: 3°. Re-torque after 50 thermal cycles.
Incompatible with:
Chlorinated solvents, ammonia-based coolants, or media containing H2S.
Not for use in oxygen-enriched atmospheres.
| Property | Property Value |
|---|---|
| sku | APH12-M20 |
