Airtac APLF L-Shaped Female Thread Elbow APLF10-01
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF10-01 Technical Details
- Model: APLF10-01
- Type: 90° L-shaped pneumatic fitting with female threads
- Thread standard: Metric (M5×0.8 female threads at both ports)
- Alternative thread: G1/8 (BSPP) available upon request
- Material: Lead-free brass CW617N
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Max working pressure: 1.5 MPa (15 bar/217.5 psi)
- Temperature range: -20℃ to 120℃ (continuous use)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Seal type: Metal-to-metal sealing (no O-ring required)
- Weight: 28g ±2g
- Dimensions:
- Center-to-center length: 18mm
- Port depth: 9mm (each side)
- Hex size: 12mm wrench flat
- Overall height: 24mm (from base to top)
- Compliance: RoHS 2.0 compliant
Precision-machined L-connector designed for high-pressure pneumatic systems requiring compact routing solutions. Features anti-vibration grooves and leak-proof tapered thread design. The nickel plating provides superior corrosion resistance against moisture and mild chemicals. Internal bore maintains 3.2mm diameter for minimal flow restriction.
- Robotic arm pneumatic circuit branching
- CNC machine tool air supply distribution
- Semiconductor manufacturing equipment
- High-cycle automation jigs (200,000+ cycles rated)
- Vacuum system plumbing in cleanrooms
Installation guide:
Apply PTFE tape or liquid sealant on male threads before assembly.
Tighten to 1.2-1.5 N·m torque using a crowfoot wrench.
Avoid overtightening - maximum 2 full turns after finger-tight.
| Property | Property Value |
|---|---|
| sku | APLF10-01 |
