Airtac APLF L-Shaped Female Thread Elbow APLF10-M16
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF10-M16 Technical Details
- Model: APLF10-M16
- Type: 90° L-shaped pneumatic fitting with female threads
- Thread Standard: Metric (M16x1.5)
- Material: Aluminum alloy 6063-T5
- Max Working Pressure: 1.0 MPa (145 psi)
- Temperature Range: -20℃ to 80℃ (continuous use)
- Seal Material: NBR (Nitrile) rubber standard (FKM available for high-temp)
- Surface Treatment: Anodized oxidation (8-12μm thickness)
- Weight: 48g ±2g
- Dimensions: 38mm (L) × 38mm (W) × 28mm (H)
- Thread Engagement Depth: 12mm minimum
- Torque Rating: 14-16 N·m (with sealant tape)
Precision-machined L-connector featuring dual-port female threads for 90° directional changes in pneumatic systems. The compact hexagonal body design allows wrench tightening while maintaining minimal footprint. Anodized surface resists corrosion in humid environments. Compatible with ISO 1179-2 standards for metric pipe connections.
- Pneumatic cylinder port redirection in robotic arms
- Space-constrained air preparation units (FRL assemblies)
- Modular pneumatic circuit prototyping
- CNC machine tool air line connections
- Packaging machine actuator networks
Installation guidance:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Use 24mm open-end wrench on flat surfaces - avoid overtightening.
For vibration-prone areas, apply thread-locking compound on external threads.
| Property | Property Value |
|---|---|
| sku | APLF10-M16 |
