Airtac APLF L-Shaped Female Thread Elbow APLF12-01
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-01 Technical Details
- Model: APLF12-01
- Thread Standard: Metric/Inch dual marking (M5×0.8 & G1/8)
- Material: Brass (CuZn39Pb3) with nickel-plated surface
- Seal Type: Integrated O-ring (NBR 70±2 Shore A)
- Pressure Rating: 0.05-1.0 MPa (7-145 psi)
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Flow Coefficient: Cv≈0.12
- Surface Roughness: Ra≤3.2μm
- Proof Pressure: 1.5 MPa (217 psi) for 3 minutes
- Weight: 18.5±0.5g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- Torque Limitation: 1.2-1.5N·m during installation
- Compatibility: Works with ISO 1179-1 standard fittings
Precision-engineered 90° flow redirection component with dual-thread compatibility, featuring anti-vibration grooves and leak-proof elliptical sealing surface. The electroless nickel plating provides enhanced corrosion resistance (96hrs salt spray test passed). Internal flow path optimized for minimal pressure drop (ΔP≤0.02MPa @0.5MPa).
- Pneumatic circuit branching in robotic end effectors
- Compact sensor mounting configurations
- Coolant line connections in CNC machining centers
- Vacuum system plumbing for semiconductor equipment
- Modular pneumatic training kits
Installation protocol:
Apply thread sealant (LOCTITE 545 or equivalent) on male threads only.
Tighten using crowfoot wrench with 15° offset tolerance.
Perform 3 pressure cycles (0-0.8MPa) for seat conditioning before final use.
| Property | Property Value |
|---|---|
| sku | APLF12-01 |
