Airtac APLF L-Shaped Female Thread Elbow APLF4-01
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF4-01 Technical Details
- Model Code: APLF4-01 (L-type 90° elbow)
- Thread Standard: Metric (M) / BSPP (G) optional
- Port Size: 1/4" (M10×1.0 / G1/4)
- Material: Lead-free brass CW617N (nickel-plated)
- Seal Material: HNBR (Hydrogenated Nitrile) standard
- Max Working Pressure: 1.5 MPa (217 psi)
- Temperature Range: -20℃ to 80℃ (dry air)
- Surface Finish: Electroless nickel plating (5-8μm)
- Torque Resistance: ≤25 N·m installation torque
- Flow Coefficient (Cv): 0.45
- Weight: 38g ±2g
- Dimensions: 32mm (L) × 28mm (W) × 24mm (H)
- Compliance: RoHS 2.0 compliant
Precision-machined L-shaped pneumatic fitting with dual-port female threads, featuring anti-vibration grooves and leak-proof double-seal structure. The hexagonal base allows wrench tightening (13mm AF). Nickel plating provides corrosion resistance for humid environments. Compatible with PU/Nylon tubing (4mm-6mm OD).
- Pneumatic cylinder port redirection in tight spaces
- Modular assembly systems requiring 90° flow path changes
- Vacuum line connections in packaging machinery
- Medical device gas delivery systems
- Robotic arm end-effector pneumatic routing
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using calibrated wrench.
Avoid overtightening to prevent thread deformation.
Pressure test at 1.8MPa after installation.
| Property | Property Value |
|---|---|
| sku | APLF4-01 |
