Airtac APLF L-Shaped Female Thread Elbow APLF4-M10
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLF4-M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Hexagonal edges with a turned outer circumference for space-saving installation;
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
Installation Guide:
Apply 2-3 drops of pneumatic sealant (LOCTITE 577 recommended) on threads.
Tighten to 12-15 N·m torque using a crowfoot wrench. Avoid overtightening
which may deform sealing surfaces. Perform pressure test at 1.8× working
pressure after installation.
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF4-M10 Technical Details
- Full Model Code: APLF4-M10
- Connection Type: L-shaped 90° elbow
- Thread Standard: Metric fine thread (internal)
- Thread Size: M10×1.0 (male) to M10×1.0 (female)
- Material: Lead-free brass CW617N (nickel-plated)
- Seal Type: Integrated O-ring groove (pre-installed NBR seal)
- Pressure Rating: 0.2-1.5 MPa (29-218 psi)
- Temperature Range: -20℃ to 80℃ (continuous use)
- Surface Finish: Electroless nickel plating (8-12μm thickness)
- Corrosion Resistance: 96hrs neutral salt spray test passed
- Weight: 28.5g ±0.5g
- Dimensions: 34mm (L) × 24mm (W) × 24mm (H)
- Center-to-Face Distance: 16mm
- Hex Size: 17mm wrench flat
- Flow Capacity: 350 NL/min (at 0.5MPa)
Precision-machined L-shaped pneumatic connector featuring dual internal threads with leak-proof design. The chamfered entry ports prevent tubing abrasion during assembly. Nickel plating enhances chemical resistance in humid or mildly corrosive environments.
Common Applications:
- Pneumatic cylinder port redirection in tight spaces
- Compact automation equipment manifolds
- Air preparation unit plumbing
- Robotic end-effector pneumatic routing
- Medical gas line installations
Installation Guide:
Apply 2-3 drops of pneumatic sealant (LOCTITE 577 recommended) on threads.
Tighten to 12-15 N·m torque using a crowfoot wrench. Avoid overtightening
which may deform sealing surfaces. Perform pressure test at 1.8× working
pressure after installation.
Matched Components:
Works with Ø4mm push-in tubing (SMC PUN-4, Festo QS-4). Compatible with
AirTAC APCS series quick connectors. Not recommended for hydraulic fluids
or aggressive chemicals.
| Property | Property Value |
|---|---|
| sku | APLF4-M10 |
