Airtac APLL Extended L Elbow APLL10-01
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLL10-01
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applied in various pneumatic systems;
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
Installation guidelines:
Apply thread sealant only on male threads (not on tube side).
Maximum 3 full rotations after hand-tightening.
Avoid side-load forces exceeding 50N during operation.
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-Type Elbow APLL10-01 Technical Details
- Model: APLL10-01
- Type: Extended L-shaped pneumatic fitting (male thread to push-in)
- Material: Nickel-plated brass (C3604)
- Thread specification: M10×1.0 male thread
- Tube compatibility: Ø10mm nylon/polyurethane tubing
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (with silicone seals)
- Seal material: HNBR (standard), optional fluororubber (FKM)
- Surface roughness: Ra ≤1.6μm (threaded portion)
- Weight: 42g ±2g
- Dimensions: 65mm(L) × 32mm(W) × 32mm(H)
- Torque limit: 15-20 N·m (thread installation)
- Flow coefficient (Cv): 2.8
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered 90° connector with extended reach for complex pneumatic routing. Features dual-stage sealing (thread + O-ring) and anti-vibration locking collar. Nickel plating provides corrosion resistance in humid environments. Compatible with ISO 8434-1 standards.
Typical Applications:
- Robotic arm pneumatic circuit transitions
- CNC machine tool coolant line connections
- Food processing equipment air supply lines
- Semiconductor manufacturing vacuum systems
- Hydraulic test bench manifold assemblies
Installation guidelines:
Apply thread sealant only on male threads (not on tube side).
Maximum 3 full rotations after hand-tightening.
Avoid side-load forces exceeding 50N during operation.
| Property | Property Value |
|---|---|
| sku | APLL10-01 |
