Airtac APLL Extended L Elbow APLL10-02
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL10-02 Extended L-Type Elbow Fitting Specifications
- Model: APLL10-02
- Type: Extended L-shaped pneumatic connector
- Thread standard: PT1/8 (BSPP) female threads
- Material: Brass with nickel plating (surface hardness ≥HV200)
- Seal material: NBR (Nitrile) rubber
- Operating pressure: 0-1.0 MPa
- Temperature range: -5℃ to 60℃
- Proof pressure: 1.5 MPa
- Flow coefficient (Cv): 0.3
- Weight: 22g ±1g
- Dimensions: 30mm (Total Length) × 25mm (Vertical Height) × 25mm (Horizontal Width)
- Installation torque: 1.0-1.5 N·m
- Thread engagement length: 8mm
- Surface roughness: Ra ≤3.2μm
- Corrosion resistance: 96hr salt spray test compliant
Precision-machined extended L-shaped fitting designed for high-density pneumatic circuit layouts. Features anti-vibration grooves and leak-proof tapered seat design, with 30% increased flow capacity compared to standard elbows. The extended profile enables easier tool access in confined spaces while maintaining minimal pressure drop (≤0.02MPa @ 0.5MPa).
- Multi-axis robotic arm pneumatic routing
- CNC machine tool coolant line connections
- Semiconductor wafer handling equipment
- Compact valve manifold assemblies
- Medical device pneumatic systems
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on male threads only.
Avoid overtightening - use torque wrench for precise installation.
Maximum angular deviation: ±3° from nominal position.
| Property | Property Value |
|---|---|
| sku | APLL10-02 |
