Airtac APLL Extended L Elbow APLL10-03
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL10-03 Extended L-Type Elbow Fitting Specifications
- Model: APLL10-03
- Type: Extended L-shaped pneumatic connector
- Material: Brass with nickel plating (stainless steel optional)
- Thread standard: PT1/8 (NPT1/8 available on request)
- Through-hole diameter: 3.5mm ±0.1mm
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 150℃
- Surface hardness: ≥HV200
- Weight: 28g ±2g
- Dimensions: 32mm(L) × 22mm(W) × 18mm(H)
- Torque resistance: ≤25N·m
- Leakage rate: ≤3×10⁻⁸ Pa·m³/s (helium test)
Precision-machined L-shaped pneumatic fitting with extended reach design (40% longer than standard models), featuring anti-vibration grooves and dual O-ring seals (NBR material). The 45° angled port alignment enables space-efficient plumbing in complex pneumatic circuits. Compatible with ISO 1179-1 standards.
- Robotic arm pneumatic tool changers
- CNC machine tool clamping systems
- Semiconductor wafer handling equipment
- High-cycle packaging machine manifolds
- Medical gas distribution panels
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (hand-tighten first 1.5 turns).
Avoid overtightening beyond 12N·m to prevent port deformation.
Recommended maintenance: Inspect O-rings every 5,000 operating hours.
| Property | Property Value |
|---|---|
| sku | APLL10-03 |
