Airtac APLL Extended L Elbow APLL10-04
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-Type Elbow APLL10-04 Technical Details
- Model: APLL10-04 (Extended L-Type)
- Thread standard: PT1/4 (BSPP) / G1/4 (BSPT)
- Tube OD compatibility: 10mm (standard pneumatic tubing)
- Material: POM (Polyoxymethylene) body, NBR seals
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 60℃ (-4°F to 140°F)
- Surface finish: Ra 3.2μm (internal flow path polished)
- Thread engagement: 12mm minimum recommended
- Weight: 15g ±0.5g
- Dimensions: 40mm(L) × 30mm(W) × 25mm(H)
- Torque rating: 3.5-4.0 N·m installation torque
- Flow coefficient: Cv ≈ 0.85
High-flow L-shaped pneumatic connector with extended reach design for complex piping layouts. Features anti-vibration grooves and 360° rotatable fitting interface. Sealing structure prevents particulate ingress in dusty environments. Compatible with ISO 15407-1 standard pneumatic systems.
- Robotic arm pneumatic circuit routing
- CNC machine tool coolant line connections
- Packaging machine rotary union interfaces
- Semiconductor equipment gas distribution
- Automated assembly line tooling fixtures
Installation guide:
Apply thread sealant only on male threads (not on tube side).
For vibration-prone environments, use with AS-04 anti-loosening clip.
Maximum angular deflection: ±2° from axis alignment.
| Property | Property Value |
|---|---|
| sku | APLL10-04 |
