Airtac APLL Extended L Elbow APLL10-M10
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL10-M10 Extended L-Type Elbow Fitting Specifications
- Model: APLL10-M10
- Type: Extended L-shaped pneumatic connector
- Thread specification: M10×1.0 (external thread both ends)
- Material: Anodized aluminum alloy 6063-T5
- Surface hardness: HV 0.2≥8μm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal type: Embedded O-ring (NBR 70±5 Shore A)
- Torque resistance: ≤25 N·m
- Weight: 28±2 grams
- Dimensions: 52mm(L) × 34mm(W) × 34mm(H)
- Flow coefficient (Cv): 0.15
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-machined L-shaped adapter featuring 90° flow redirection with extended reach for complex pneumatic layouts. The anodized surface provides enhanced corrosion resistance against hydraulic oils and mild chemicals. Optimized internal bore (φ4.2mm) minimizes pressure drop while maintaining structural integrity.
- Robotic arm pneumatic circuit routing
- CNC machine tool coolant line connections
- Packaging machinery air distribution networks
- Semiconductor wafer handling equipment
- Medical device pneumatic control systems
Installation guidance:
Apply 2-3 wraps of PTFE tape on male threads (max 7Nm tightening torque).
Avoid cross-threading by hand-starting connections. Compatible with
Ø6-8mm polyurethane/nylon tubing using standard collet clamps.
| Property | Property Value |
|---|---|
| sku | APLL10-M10 |
