Airtac APLL Extended L Elbow APLL10-M12
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-Type Elbow APLL10-M12 Technical Details
- Model: APLL10-M12 (Extended L-Type)
- Material: Nickel-plated brass (Stainless steel variant available)
- Thread Specification: M12×1.25 external thread (ISO metric standard)
- Center-to-End Length: 42±0.5mm (Extended profile)
- Bend Radius: 15mm (Precision right-angle design)
- Weight: 48g ±2g (Brass version) / 68g ±3g (Stainless steel)
- Operating Temperature: -20℃ to 100℃ (Brass) / -40℃ to 200℃ (Stainless)
- Max Working Pressure: 1.0MPa (10bar)
- Surface Finish: Electrostatic epoxy coating (Anti-corrosion)
- Seal Type: Integrated O-ring groove (NBR seal pre-installed)
- Installation Torque: 3-5Nm (Brass) / 6-8Nm (Stainless)
- Flow Characteristics: 0.8 Cv value (Optimized internal bore geometry)
- Vibration Resistance: ≤15Hz frequency, 1.5mm amplitude
Extended L-shaped pneumatic connector featuring a 25% longer profile than standard elbows, designed for complex piping layouts requiring clearance from adjacent components. The precision-machined internal passage reduces turbulent flow (pressure drop ≤0.02MPa @ 0.5MPa). Dual-material options accommodate both general industrial and corrosive environments.
- Robotic arm end-effector pneumatic routing
- Multi-axis CNC machine tool coolant line connections
- Pharmaceutical equipment requiring frequent disassembly
- High-vibration environments like injection molding machines
- Vacuum system manifolds with space constraints
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (Do NOT over-tighten).
For stainless steel version, use anti-seize compound.
Maximum angular deviation: ±3° during alignment.
Pressure test recommended after installation.
| Property | Property Value |
|---|---|
| sku | APLL10-M12 |
