Airtac APLL Extended L Elbow APLL10-M16
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Series Extended L-Elbow APLL10-M16 Technical Details
- Model: APLL10-M16
- Type: Extended L-shaped pneumatic fitting (male thread)
- Material: Aluminum alloy 6063-T5 with hard anodized surface
- Thread Specification: M16×1.5 external thread (ISO 228-1 standard)
- Pressure Range: 0.05-0.8 MPa (7-116 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: NBR (Nitrile) rubber (optional FKM/Viton®)
- Surface Finish: Black oxidation with 25μm coating thickness
- Weight: 120g ±5g
- Dimensions: 80mm(Total L) × 50mm(Elbow L) × 18mm(Ø)
- Height: 40mm (Vertical projection)
- Flow Capacity: 650 NL/min (at 0.5 MPa)
- Compliance: RoHS compliant, ISO 9001 certified
Extended L-shaped pneumatic connector designed for high-density piping layouts requiring directional changes in confined spaces. Features anti-vibration grooves and precision-machined threads for leak-free connections. The extended arm allows tube routing around obstacles while maintaining laminar airflow.
- Robotic arm end effector pneumatic circuits
- CNC machine tool clamp manifolds
- Packaging line actuator clusters
- Semiconductor wafer handling systems
- Medical device pneumatic control panels
Installation protocol:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Torque to 18-22 N·m using flank contact wrench.
Perform pressure test at 1.25× operating pressure after 24hrs.
| Property | Property Value |
|---|---|
| sku | APLL10-M16 |
