Airtac APLL Extended L Elbow APLL10-M20
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL10-M20 Extended L-Type Elbow Fitting Specifications
- Model: APLL10-M20
- Type: Extended L-shaped pneumatic connector
- Thread specification: M20×1.5 (male thread)
- Port size: Ø10mm tube compatible
- Material: Brass with nickel plating (CuZn39Pb3)
- Surface hardness: ≥HV200
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.2-1.0 MPa
- Temperature range: -20℃ to 80℃
- Proof pressure: 1.5 MPa
- Weight: 52±2g
- Dimensions: 58mm(L) × 22mm(W) × 22mm(H)
- Rotation capability: 360° adjustable orientation
- Vibration resistance: ≤10Hz @ 1.5mm amplitude
Heavy-duty extended L-shaped fitting designed for high-pressure pneumatic systems requiring directional flow control. Features precision CNC-machined threads with leak-proof double-sealing structure (metal-to-metal + elastic seal). The extended neck (15mm longer than standard L-fittings) enables easier tool access in congested installations.
- Pneumatic cylinder manifold connections
- Robotic arm tooling air supply lines
- Packaging machine rotary joint interfaces
- CNC equipment coolant line diversions
- Semiconductor fab gas distribution systems
Installation note:
Apply 3-5Nm torque during assembly using flank-oriented wrench.
Use thread sealant only on male threads (PTFE tape prohibited).
Perform pressure test at 0.8MPa for 3min post-installation.
| Property | Property Value |
|---|---|
| sku | APLL10-M20 |
