Airtac APLL Extended L Elbow APLL12-01
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-Type Elbow APLL12-01 Technical Details
- Model: APLL12-01
- Type: Extended L-shaped pneumatic fitting
- Thread standard: BSPP (G thread)
- Port size: 1/8" (M5 adapter compatible)
- Material: Anodized aluminum alloy 6063-T5
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Surface hardness: HV 120±15
- Weight: 28g ±0.5g
- Dimensions: 32mm(L) × 16.5mm(W) × 16.5mm(H)
- Flow coefficient (Cv): 0.12
- Leakage rate: ≤3 bubbles/min (ISO 6952-3 test)
- Certification: RoHS compliant
Precision-engineered extended L-shaped connector featuring 30% longer flow path than standard elbows, reducing turbulence by 18% in pneumatic systems. The chamfered internal bore (2.8mm ID) ensures smooth airflow transition, while the double-sealing structure prevents leakage under vibration conditions.
- High-cycle automation equipment requiring directional changes in tight spaces
- Modular pneumatic systems with limited component clearance
- Robotic arm end effectors needing vibration-resistant connections
- Medical device pneumatic circuits requiring hygienic smooth-bore design
- Semiconductor manufacturing equipment with space constraints
Installation protocol:
Apply 0.2-0.5Nm torque during assembly. Use thread sealant only on male threads.
For vertical installations exceeding 3m/s flow velocity, install support bracket within 50mm.
| Property | Property Value |
|---|---|
| sku | APLL12-01 |
