Airtac APLL Extended L Elbow APLL12-02
$5.39
Regular price
$12.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLL12-02
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applied in various pneumatic systems;
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
Mounting guidance:
Apply 2-3 wraps of PTFE tape on male threads (Do NOT over-tighten -
recommended torque 1.2-1.5N·m). Compatible with pneumatic tubing
OD 6mm or 8mm. For vertical installations, orient bend downward
to prevent moisture accumulation.
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-shaped Elbow APLL12-02 Technical Details
- Model: APLL12-02
- Type: Extended L-shaped pneumatic connector
- Material: Brass with nickel plating (CuZn39Pb3)
- Thread specification: PT1/8 (BSPP) female threads both ends
- Bend angle: 90° ±0.5° precision machining
- Max working pressure: 1.5 MPa (217 psi)
- Min burst pressure: 6 MPa (870 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) O-rings
- Surface roughness: Ra ≤1.6μm at flow paths
- Weight: 32g ±2g
- Dimensions: 28mm (L) × 20mm (W) × 34mm (H)
- Effective length: 16mm straight section before bend
- Flow coefficient (Cv): 0.15
- Corrosion resistance: 96hrs salt spray test passed
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered L-shaped pneumatic fitting with extended straight section for improved flow dynamics. Features triple-layer nickel plating (5-8μm thickness) for corrosion protection in humid environments. The 45° chamfered thread entry prevents tubing damage during installation.
Installation Scenarios:
- Space-constrained pneumatic circuit routing in robotic arms
- High-cycle automation equipment requiring vibration-resistant connections
- Coolant-resistant connections in CNC machine tool manifolds
- Medical gas line distribution systems requiring smooth internal surfaces
- Vacuum system plumbing with leak-free requirements
Mounting guidance:
Apply 2-3 wraps of PTFE tape on male threads (Do NOT over-tighten -
recommended torque 1.2-1.5N·m). Compatible with pneumatic tubing
OD 6mm or 8mm. For vertical installations, orient bend downward
to prevent moisture accumulation.
Verified Compatibility:
- Works with AirTAC PIS series push-to-connect fittings
- Tested for 50,000+ cycles with ISO 8573-1 Class 3 air quality
- Chemical-resistant to SKYDEX 500-LV lubricants
| Property | Property Value |
|---|---|
| sku | APLL12-02 |
