Airtac APLL Extended L Elbow APLL12-03
$5.39
Regular price
$12.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLL12-03
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applied in various pneumatic systems;
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
Installation guidance:
Apply 2-3 wraps of PTFE tape on male threads (not included).
Tighten to 12-15 N·m torque using offset wrench flats.
Avoid overtightening - maximum 1/4 turn past finger-tight.
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL12-03 Extended L-Type Elbow Fitting Specifications
- Model: APLL12-03
- Type: Extended L-shaped pneumatic connector
- Material: Nickel-plated brass (base), NBR/FKM seals
- Thread specification: G1/8 (BSPP) female threads both ends
- Center-to-center length: 40±0.5mm
- Bend radius: 12mm
- Max working pressure: 1.5 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Surface finish: Electrostatic epoxy coating
- Weight: 52g ±2g
- Dimensions: 40mm(L) × 24mm(W) × 24mm(H)
- Flow coefficient (Cv): 0.85
- Vibration resistance: ≤10Hz @ 1.5mm amplitude
Extended profile L-fitting with 90° directional change, featuring reinforced wall thickness (1.8mm) at stress points. The extended design allows easier tool access during installation compared to standard elbows. Compatible with ISO 1179-2 standards.
Typical Applications:
- Pneumatic cylinder manifold re-routing
- CNC machine tool air line configurations
- Compressed air systems requiring vibration dampening
- Robotic arm end effector plumbing
- Vacuum circuit bypass connections
Installation guidance:
Apply 2-3 wraps of PTFE tape on male threads (not included).
Tighten to 12-15 N·m torque using offset wrench flats.
Avoid overtightening - maximum 1/4 turn past finger-tight.
Compatible with:
- AirTAC APCU series push-to-connect fittings
- ISO 6149 metric adapters
- Most 1/8 BSPP threaded components
| Property | Property Value |
|---|---|
| sku | APLL12-03 |
