Airtac APLL Extended L Elbow APLL12-04
$5.91
Regular price
$13.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLL12-04
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applied in various pneumatic systems;
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
Installation note:
Apply 1.5-2 wraps of PTFE tape clockwise. Tighten to 0.8-1.2N·m torque.
For POM version, use 60% reduced torque and avoid chemical cleaners.
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL12-04 Extended L-Type Elbow Fitting Specifications
- Model: APLL12-04
- Type: Extended L-shaped pneumatic connector
- Material: Nickel-plated brass (standard) / Optional POM version
- Interface size: 1/4" (12mm nominal)
- Thread specification: PT1/8 (BSPP) female threads
- Temperature range: -20℃ to 80℃
- Pressure range: 0-1.0 MPa
- Surface treatment: Electrolytic polishing + anti-oxidation coating
- Weight: 48g ±2g
- Dimensions: 40mm(L) × 21mm(W) × 21mm(H)
- Torque resistance: ≤1.5N·m
- Flow coefficient (Cv): 0.85
Extended-length L-shaped fitting with precision-machined internal channels for minimal pressure drop. Features 30% increased bend radius compared to standard elbows, reducing turbulence. Sealing achieved through metal-to-metal contact with optional thread sealant compatibility.
Typical Applications:
- High-cycle automation equipment manifolds
- Pneumatic tool hose routing systems
- CNC machine tool air circuit distribution
- Packaging machinery air line reorganization
- Robotic arm end-effector connections
Installation note:
Apply 1.5-2 wraps of PTFE tape clockwise. Tighten to 0.8-1.2N·m torque.
For POM version, use 60% reduced torque and avoid chemical cleaners.
Compatible Accessories:
- APET12 series push-to-connect fittings
- APU12-02 pneumatic union nuts
- ASM12 modular manifold blocks
| Property | Property Value |
|---|---|
| sku | APLL12-04 |
