Airtac APLL Extended L Elbow APLL12-M12
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-shaped Elbow APLL12-M12 Technical Details
- Model: APLL12-M12
- Type: Extended L-shaped pneumatic connector
- Material: Brass (Nickel-plated) / Stainless Steel (Optional)
- Thread specification: M12×1.5 (ISO metric fine thread)
- Elbow angle: 90° ±0.5° precision bent
- Extended length: 28mm (standard variant: 18mm)
- Inner diameter: 12mm (ID tolerance: ±0.15mm)
- Pressure range: 0.05–1.0 MPa (7–145 PSI)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Seal material: NBR (Standard) / FKM (Fluorocarbon optional)
- Installation torque: 20-25 Nm (Brass) / 25-30 Nm (Stainless Steel)
- Weight: 25g ±2g (Brass) / 38g ±3g (Stainless Steel)
- Dimensions: 28mm(L) × 18mm(W) × 18mm(H)
- Surface roughness: Ra ≤3.2μm (internal flow path)
- Compliance: RoHS 2011/65/EU
Precision-engineered extended L-shaped elbow featuring a 4-stage electroplating process for corrosion resistance. The extended design (40% longer than standard APL series) enables easier tube routing in congested pneumatic systems while maintaining laminar flow characteristics. Internal mirror polishing minimizes pressure drop (ΔP ≤0.02MPa at 1.0MPa input).
- Multi-axis robotic arm pneumatic circuits requiring tight bend radius
- Modular pneumatic manifolds with space constraints
- High-cycle automation equipment needing vibration-resistant connections
- Cleanroom-compatible machinery (stainless steel variant)
- Plastic injection molding machine hydraulic line conversions
Installation protocol:
Apply thread sealant (PTFE tape or liquid sealant) on male threads only.
Tighten using crowfoot wrench with torque limiter - do not exceed specified torque values.
Perform pressure test at 1.5× operating pressure after installation.
- AirTAC SDA series compact cylinders
- APM-M12 modular pneumatic manifolds
- 10mm OD polyurethane tubing (APTU-10)
- VFRB-12 flow control valves
| Property | Property Value |
|---|---|
| sku | APLL12-M12 |
