Airtac APLL Extended L Elbow APLL12-M20
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Series Extended L-Type Elbow APLL12-M20 Technical Details
- Model: APLL12-M20
- Type: Extended L-shaped pneumatic fitting (90° elbow)
- Thread specification: M20×1.5 (external thread both ends)
- Material: Cold forged brass CW617N (chrome-plated surface)
- Seal material: NBR (Nitrile) O-ring
- Tube compatibility: Ø12mm outer diameter pneumatic tubing
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃ (non-condensing)
- Torque resistance: ≤50 N·m
- Surface hardness: HV0.3 130-250 (chrome layer)
- Weight: 182±5g
- Dimensions: 76mm(L) × 52mm(W) × 38mm(H)
- Center-to-center port distance: 63mm
Extended-length L-shaped connector with reinforced wall thickness (1.8mm minimum), designed for high-vibration environments requiring durable flow path redirection. Features triple-layer chrome plating (8-12μm) for corrosion resistance in humid conditions. The 45° chamfered thread ends prevent O-ring damage during installation.
- Robotic arm pneumatic line routing
- CNC machine tool coolant system connections
- Food processing equipment with frequent washdowns
- Hydraulic test bench manifold assemblies
- Compressed air distribution in tight cabinet spaces
Installation protocol:
Apply 2-3 drops of pneumatic sealant (PST-3 type) on threads before assembly.
Tighten using 32mm open-end wrench with 25-30 N·m torque.
Avoid overtightening which may deform O-ring groove geometry.
| Property | Property Value |
|---|---|
| sku | APLL12-M20 |
