Airtac APLL Extended L Elbow APLL14-02
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL14-02 Extended L-Type Elbow Fitting Specifications
- Model: APLL14-02
- Type: Extended 90° L-shaped pneumatic connector
- Material: Nickel-plated brass (base), PPS resin (housing)
- Thread Standard: G1/4 (BSPP) female threads both ends
- Max Working Pressure: 1.0 MPa (145 psi)
- Temperature Range: -5℃ to 80℃ (non-condensing)
- Weight: 48g ±2g
- Dimensions: 42mm(L) × 32mm(W) × 56mm(H)
- Flow Capacity: 350 NL/min (at 0.5 MPa)
- Seal Material: Fluororubber (FKM)
- Surface Treatment: Electroless nickel plating (3-5μm)
- Vibration Resistance: 10-55Hz, 1.5mm double amplitude
Extended L-shaped fitting with corrosion-resistant construction, designed for high-density pneumatic circuit layouts requiring directional changes. Features dual-stage sealing (metal-to-metal primary seal + O-ring secondary seal) for leak-free performance in vibration-prone environments. The extended neck design allows tool-free adjustment of hose orientation.
- Robotic arm pneumatic gripper manifolds
- CNC machine tool clamp circuits
- Packaging machine rotary joint connections
- Semiconductor wafer handling equipment
- Automated assembly line tooling
Installation note:
Apply 2-3 drops of pneumatic sealant (LOCTITE® 577 equivalent) on male threads before assembly.
Maximum recommended torque: 15 N·m. Avoid simultaneous tightening of both ports - secure one side first then rotate fitting body.
| Property | Property Value |
|---|---|
| sku | APLL14-02 |
