Airtac APLL Extended L Elbow APLL14-03
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-Type Elbow APLL14-03 Technical Details
- Model: APLL14-03
- Type: Extended L-shaped pneumatic fitting (male thread)
- Material: Brass with nickel plating
- Seal material: NBR (Nitrile) rubber
- Thread specification: M5×0.8 (male)
- Port size: 1/4" tube OD compatible
- Working pressure: 0-1.0 MPa
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Proof pressure: 1.5 MPa
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 22mm(W) × 38mm(H)
- Bend radius: 14mm centerline
- Surface roughness: Ra0.8μm (internal flow path)
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
Extended-length L-connector with precision-machined flow channels, designed for compact pneumatic systems requiring directional changes without flow restriction. Features anti-vibration thread locking design and oxidation-resistant finish. The extended profile allows easier tool access in dense component arrangements.
- Robotic arm pneumatic circuit routing
- CNC machine tool clamping systems
- Semiconductor manufacturing equipment
- High-cycle automation fixtures
- Medical device pneumatic assemblies
Installation guidance:
Apply 1.5-2 wraps of PTFE tape on male threads. Tighten to 1.2-1.5N·m torque.
Avoid installing at angles exceeding 15° from primary axis. Compatible with ISO 8434-1/DIN 2353 fittings.
| Property | Property Value |
|---|---|
| sku | APLL14-03 |
