Airtac APLL Extended L Elbow APLL14-04
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL14-04 Extended L-shaped Elbow Specifications
- Model: APLL14-04
- Type: Extended L-shaped pneumatic fitting
- Material: Nylon 6 (PA6) with glass fiber reinforcement
- Thread standard: G1/4 (BSPP parallel thread)
- Temperature range: -20℃ to 80℃
- Max working pressure: 1.5 MPa
- Burst pressure: ≥4.5 MPa
- Weight: 35g ±2g
- Dimensions:
- Total length: 48mm
- Vertical leg length: 28mm
- Horizontal leg length: 20mm
- Outer diameter: 14mm
- Inner diameter: 7.5mm (flow path)
- Surface finish: Smooth injection-molded
- Color: Natural nylon (off-white)
- Compliance: RoHS compliant
Reinforced L-shaped connector designed for high-pressure pneumatic systems requiring extended reach and 90° flow direction changes. Features chemical-resistant construction with 30% glass fiber reinforcement for improved structural integrity. The elongated design allows easier access in deep panel mounts and provides strain relief for tubing.
- Industrial robotic arm pneumatic circuits
- CNC machine tool air supply lines
- Packaging machinery air distribution
- Automated assembly line manifolds
- Semiconductor equipment gas delivery
Installation guidance:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 1.2-1.5 N·m torque.
Ensure elbow orientation aligns with tubing path to prevent torsion stress.
Not recommended for continuous rotation applications.
- CV value: 0.15
- Pressure drop: ≤0.02 MPa at 500 L/min
- Optimal flow rate: 200-400 L/min (ANR)
| Property | Property Value |
|---|---|
| sku | APLL14-04 |
