Airtac APLL Extended L Elbow APLL16-03
$14.18
Regular price
$21.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLL16-03
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applied in various pneumatic systems;
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
Installation guidelines:
Apply 2-3 wraps of PTFE tape clockwise. Tighten with 12-15N·m torque using backup wrench.
Perform pressure test at 1.5x operating pressure after installation. Avoid overtightening
which may cause thread deformation.
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL16-03 Extended L-Type Elbow Fitting Specifications
- Model: APLL16-03
- Type: Extended L-shaped pneumatic connector (90° right angle)
- Material: Brass with nickel plating (stainless steel optional)
- Port size: PT1/8 (G1/8, NPT1/8 compatible)
- Thread length: 8mm (male threads on both ends)
- Working pressure: 0-1.0 MPa (145 psi max)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Surface roughness: Ra ≤1.6μm
- Weight: 28g ±2g
- Dimensions: 40mm(L) × 20mm(W) × 20mm(H)
- Center-to-center distance: 25mm between ports
- Seal compatibility: Works with PTFE tape or liquid thread sealant
- Corrosion resistance: 96hr salt spray test passed
Precision-machined extended L-shaped fitting designed for high-density pneumatic layouts requiring directional changes with extended reach. Features anti-vibration grooves and leak-proof tapered threads. The extended design allows clearance for tool access in tight assemblies.
Typical Applications:
- Robotic arm pneumatic circuit routing
- Modular pneumatic manifolds with space constraints
- CNC machine tool air supply systems
- Medical device gas line connections
- Packaging machine actuator networks
Installation guidelines:
Apply 2-3 wraps of PTFE tape clockwise. Tighten with 12-15N·m torque using backup wrench.
Perform pressure test at 1.5x operating pressure after installation. Avoid overtightening
which may cause thread deformation.
Note: Compatible with ISO 1179-1 standard fittings. For vacuum applications
(down to -100kPa), use anaerobic sealant instead of PTFE. Not recommended for continuous
thermal cycling above 60℃ without thermal insulation.
| Property | Property Value |
|---|---|
| sku | APLL16-03 |
