Airtac APLL Extended L Elbow APLL16-04
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Series Extended L-Type Elbow APLL16-04 Technical Details
- Model: APLL16-04
- Type: Extended L-shaped pneumatic fitting (90° elbow)
- Thread standard: PT1/4 (BSPP)
- Material: Brass with nickel-plated surface
- Seal type: Integrated O-ring (NBR material)
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Flow coefficient (Cv): ~0.35
- Weight: 120g ±5g
- Dimensions: 42mm(L) × 42mm(W) × 58mm(H)
- Extended shank length: 28mm (unique to APLL series)
- Surface roughness: Ra ≤1.6μm
- Vibration resistance: 10-2000Hz, 5G max
Precision-engineered extended L-shaped connector featuring enhanced flow path geometry for reduced turbulence. The extended neck design (28mm) allows secure grip during installation and prevents thread cross-threading. Nickel plating provides corrosion resistance in humid environments while maintaining compatibility with most pneumatic fluids including synthetic oils.
- High-vibration pneumatic systems (e.g., stamping machines)
- Compact robotic arm end-effector plumbing
- Modular pneumatic circuit prototyping
- Coolant-resistant applications (CNC machine tooling)
- Multi-axis actuator connections requiring angled fittings
Installation protocol:
Hand-tighten plus 1/4 turn with wrench (max torque 15N·m).
Apply PTFE tape clockwise on male threads. Avoid using pipe sealants containing silicone.
| Property | Property Value |
|---|---|
| sku | APLL16-04 |
