Airtac APLL Extended L Elbow APLL16-M20
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Series Extended L-Elbow APLL16-M20 Technical Details
- Model: APLL16-M20
- Type: Extended L-shaped pneumatic fitting (male thread)
- Material: Brass with nickel plating (anti-corrosion treatment)
- Thread specification: M20×1.5 (ISO metric standard)
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Surface roughness: Ra ≤3.2μm
- Proof pressure: 1.5 MPa (217.5 psi)
- Weight: 0.25kg ±5%
- Dimensions: 80mm (Total Length) × 50mm (L1) × 60mm (L2)
- Turn radius: 12mm (internal flow path optimization)
- Installation torque: 30-35 N·m (22.1-25.8 lbf·ft)
Precision-engineered extended L-shaped connector featuring enhanced flow dynamics with a 25% larger internal passage compared to standard elbows. The extended arm design (L2 dimension) allows deeper engagement in confined spaces while maintaining 360° rotational adjustability. Nickel-plated surface provides chemical resistance against hydraulic oils and mild solvents.
- Pneumatic cylinder port extensions in robotic arms
- Compressed air distribution in automotive assembly lines
- Vacuum system connections for packaging machinery
- Coolant line routing in CNC machine tools
- Modular pneumatic circuit building for factory automation
- Instrumentation gas lines in semiconductor manufacturing
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (clockwise winding).
Use dual wrenches - hold base hex with 24mm spanner while tightening
with 27mm crowfoot wrench. Avoid overtightening beyond 40N·m to
prevent thread deformation. Post-installation pressure test required.
| Property | Property Value |
|---|---|
| sku | APLL16-M20 |
