Airtac APLL Extended L Elbow APLL4-01
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL4-01 Extended L-Type Elbow Fitting Specifications
- Model: APLL4-01
- Type: Extended L-shaped pneumatic connector (90° bend)
- Material: Brass (nickel-plated) / Optional stainless steel AISI303
- Thread type: Rc (PT) female threads both ends
- Port size: Rc1/8 (1/8" BSPT)
- Max working pressure: 0.05-0.8 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Surface roughness: Ra ≤1.6μm
- Torsion strength: ≥25 N·m
- Weight: 32g (brass) / 45g (stainless steel)
- Dimensions: 40mm(Total L) × 25mm(W) × 25mm(H)
- Bend radius: 8mm (internal flow path optimized)
- Seal material: NBR (standard), optional FKM for oil resistance
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
Precision-machined extended L-fitting with enhanced flow characteristics, featuring anti-vibration grooves and leak-proof secondary sealing. The extended design provides 15% more installation clearance compared to standard L-fittings. Electroless nickel plating offers 480h salt spray resistance (per ASTM B117).
- Robotic arm pneumatic line routing
- CNC machine tool air circuit branching
- Pharmaceutical equipment gas distribution
- Semiconductor fab pneumatic systems
- High-cycle automation fixtures
- Marine equipment corrosion-resistant piping
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (Do NOT over-tighten - max torque 18N·m).
For vertical installations, orient the bend downward to prevent condensate pooling.
Pressure test at 1.2MPa after assembly.
| Property | Property Value |
|---|---|
| sku | APLL4-01 |
