Airtac APLL Extended L Elbow APLL4-02
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLL4-02
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applied in various pneumatic systems;
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
Installation note:
Apply thread sealant (PTFE tape or liquid seal) on male threads only.
Tighten with proper torque wrench - over-tightening may deform sealing surfaces.
Recommended maintenance: Inspect O-rings every 2,000 operating hours.
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL4-02 Extended L-Type Elbow Fitting Specifications
- Model: APLL4-02
- Type: Extended L-shaped pneumatic connector
- Thread standard: BSPP (G thread)
- Port size: 1/4" (NPT optional)
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-rings
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃
- Surface treatment: Electroplated anti-corrosion coating
- Weight: 38g ±2g
- Dimensions: 52mm(Length) × 32mm(Width) × 32mm(Height)
- Bend radius: 12mm internal flow path
- Torque resistance: ≤3 N·m installation torque
Extended L-shaped pneumatic fitting designed for confined space installations requiring directional flow changes. Features enhanced wall thickness (1.8mm) for high-pressure applications and 360° rotatable collar for easy alignment. Compatible with ISO 1179-2 standard pneumatic systems.
Typical Applications:
- Robotic arm pneumatic circuit routing
- CNC machine tool air supply systems
- Packaging machinery air line distribution
- Semiconductor equipment vacuum/pressure lines
- Medical device compressed air connections
Installation note:
Apply thread sealant (PTFE tape or liquid seal) on male threads only.
Tighten with proper torque wrench - over-tightening may deform sealing surfaces.
Recommended maintenance: Inspect O-rings every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | APLL4-02 |
