Airtac APLL Extended L Elbow APLL4-M10
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL4-M10 Extended L-shaped Elbow Specifications
- Model: APLL4-M10 (APLL Series)
- Type: Extended L-shaped pneumatic fitting
- Material: Nickel-plated brass (corrosion resistant)
- Thread specification: M10×1.0 male threads (both ends)
- Bend angle: 90° precision machining
- Seal material: NBR (Nitrile) O-ring
- Temperature range: -20℃ to 80℃
- Pressure range: 0-1.0 MPa (145 psi)
- Weight: 18g ±0.5g
- Dimensions: 40mm(L) × 25mm(W) × 15mm(H)
- Surface roughness: Ra ≤3.2μm
- Flow coefficient: Cv≈0.15
- Compatible tubing: Ø4mm pneumatic lines
Precision-engineered L-shaped connector featuring extended reach design for enhanced installation flexibility in confined spaces. The nickel-plated construction ensures corrosion resistance in humid environments, while the 3D-forged body provides superior burst pressure resistance. Sealed with oil-resistant NBR rings for leak-free operation in lubricated air systems.
- Compact pneumatic cylinder installations
- Multi-axis robotic arm pneumatic routing
- Medical equipment gas line connections
- CNC machine tool air circuit distribution
- Packaging machinery sensor air supply
Installation protocol:
Apply 2-3 drops of thread sealant (LOCTITE 577 recommended) on male threads before assembly.
Tighten to 12-15N·m torque using crowfoot wrench. Avoid overtightening to prevent port deformation.
| Property | Property Value |
|---|---|
| sku | APLL4-M10 |
