Airtac APLL Extended L Elbow APLL4-M12
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL4-M12 Extended L-Type Elbow Fitting Specifications
- Model: APLL4-M12
- Type: Extended L-shaped pneumatic connector (90° bend)
- Thread standard: M12×1.25 (external thread)
- Compatible tube OD: Ø4mm (1/8")
- Material: Nickel-plated brass (C3604)
- Pressure rating: 0.05–1.0 MPa
- Temperature range: -20℃ to 120℃
- Seal material: NBR (Nitrile) rubber
- Surface treatment: Electroplated anti-corrosion layer
- Weight: 28g ±1g
- Dimensions: 42mm(L) × 34mm(W) × 22mm(H)
- Torque resistance: ≤25 N·m
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered extended L-shaped fitting with enhanced flow path design, featuring a 20% longer bend radius compared to standard elbows for reduced air turbulence. The nickel-plated construction ensures corrosion resistance in humid environments while maintaining compatibility with most pneumatic fluids including lubricated air.
- Compact robotic arm pneumatic circuits
- CNC machine tool air supply routing
- Packaging line actuator connections
- Laboratory equipment gas line configurations
- Automated assembly system manifold extensions
Installation guidelines:
Apply 2-3 drops of thread sealant (PTFE-based) before assembly.
Tighten using a 17mm open-end wrench with maximum torque of 18 N·m.
Avoid overtightening to prevent thread deformation.
For vertical installations, orient the elbow opening downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | APLL4-M12 |
