Airtac APZA Cross Fitting APZA10
2. Available in multiple models and specifications, widely applicable across various pneumatic systems;
3. Superior flow performance allows unimpeded passage of fluid volumes equivalent to the inner diameter of connected tubing;
4. Features push-to-connect functionality for swift tube assembly, with durable and secure connections ensuring long-term reliability.
Category: Cross Type Four-Way Fittings , Brand: AIRTAC , Series: APZA
AirTAC APZA Cross Fitting APZA10 Technical Details
- Model: APZA10
- Type: 4-way cross connector (straight thread)
- Port size: PT1/8 (G1/8 equivalent)
- Material: Brass with nickel plating
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 3.0 MPa
- Burst pressure: 6.0 MPa
- Temperature range: -20℃ to 80℃
- Surface hardness: HV0.3 ≥130
- Thread standard: ISO 1179-1 (BSPP)
- Weight: 35g ±2g
- Dimensions: 20mm × 20mm × 20mm (L×W×H)
- Seal compatibility: Works with NBR, FKM, or PTFE seals
- Corrosion resistance: 96hrs neutral salt spray test passed
Precision-machined cross connector featuring zero-leak design with 360° radial sealing surface. The electroless nickel plating provides enhanced corrosion resistance against water, weak acids, and alkalis. Four symmetrical ports enable multi-directional pneumatic circuit branching in compact installations.
- Modular pneumatic control systems
- Multi-axis robotic end effectors
- Plastic injection molding machine air circuits
- Laboratory analytical instrument gas distribution
- Semiconductor manufacturing equipment
- Packaging machine pneumatic logic systems
Installation guidelines:
Apply 1.5-2 wraps of PTFE tape on male threads (do not over-tighten - recommended torque 1.2-1.5N·m).
Avoid using pipe sealants containing silicone. Compatible with tubing OD: 6mm or 8mm.
| Property | Property Value |
|---|---|
| sku | APZA10 |
