Airtac B52-BB Non-Copper Double Male Thread Straight Connector B52-BB0101
AirTAC B52-BB0101 Non-Copper Double External Thread Straight Connector Specifications
- Model: B52-BB0101
- Type: Brass-free dual male threaded straight union
- Thread Standard: G1/8 (ISO228-1 compliant)
- Material: SUS303 Stainless Steel (copper-free design)
- Seal Material: FKM Fluororubber (Viton® equivalent)
- Pressure Rating: 0.05-1.2 MPa
- Temperature Range: -20℃ to 150℃
- Surface Treatment: Electropolished (Ra ≤0.8μm)
- Weight: 24.5g ±0.3g
- Dimensions: 30mm(L) × 12mm(Ø) × 12mm(thread length)
- Thread Tolerance: 6g for external threads
- Max Torque: 12 N·m
- Certifications: RoHS 2011/65/EU, REACH SVHC 219
Precision-machined corrosion-resistant connector featuring dual counter-rotational wrench flats for secure installation. Electropolished internal flow path minimizes pressure drop (ΔP ≤0.003MPa @1.0MPa). Compatible with aggressive media including steam, weak acids, and alkaline solutions.
- Ultra-clean pneumatic systems in semiconductor manufacturing
- Chemical dosing lines in water treatment plants
- Sterilizable connections in pharmaceutical equipment
- High-cycle automation tools requiring copper-free compliance
- Marine hydraulic instrumentation systems
Installation protocol:
Apply thread sealant (LOCTITE® 577 recommended) to male threads before assembly.
Tighten using opposing wrenches on hexagonal flats - final torque should reach 9-10 N·m
in three progressive stages. Post-installation pressure test required.
Copper contamination alert:
Do NOT use with copper-containing alloys or in systems previously containing brass components
without full decontamination. Compatible only with copper-free certified systems.
| Property | Property Value |
|---|---|
| sku | B52-BB0101 |
