Airtac BPMF Full Metal Internal Thread Bulkhead Straight Fitting BPMF602
$5.44
Regular price
$12.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BPMF602
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC BPMF602 Full Metal Bulkhead Straight Thread Fitting Specifications
- Model: BPMF602
- Type: Female-threaded bulkhead fitting (two-way)
- Material: CNC-machined stainless steel 303
- Thread type: G1/8 internal threads both ends (ISO228-1 standard)
- Pressure rating: 1.5 MPa (217 psi) maximum working pressure
- Temperature range: -30℃ to 150℃
- Seal type: Integrated copper crush washer (replaceable)
- Mounting style: Panel-mounted with hex collar (10mm wrench flat)
- Surface treatment: Electropolished finish (Ra ≤0.8μm)
- Weight: 28g ±1g
- Dimensions: 32mm total length × 16mm OD × 6mm panel thickness capacity
- Fluid compatibility: Air, inert gases, hydraulic fluids (Petroleum-based)
Heavy-duty bulkhead connector featuring zero-leak through-panel installation, designed for high-vibration environments. The dual-ported design allows 360° rotation after mounting for optimal hose routing. Features anti-galling threads with nickel-plated collar for corrosion resistance.
Typical Applications:
- Hydraulic power unit manifold connections
- CNC machine tool coolant line passthroughs
- Food processing equipment steam line installations
- Robotic arm pneumatic supply interfaces
- Semiconductor fab gas distribution panels
Installation protocol:
Use 8-10Nm torque during panel mounting. Apply thread sealant ONLY on stationary port side.
Replace copper washer every 5 disassemblies. Max panel deformation under load: ≤0.1mm.
| Property | Property Value |
|---|---|
| sku | BPMF602 |
