Airtac BPMF Full Metal Internal Thread Bulkhead Straight Fitting BPMF802
AirTAC BPMF802 Full Metal Female Thread Bulkhead Union Specifications
- Model: BPMF802
- Type: Through-panel bulkhead union with female threads
- Thread standard: G1/8 (BSPP)
- Material: Stainless steel 303/PTFE composite
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Temperature range: -20℃ to 150℃ (static) / -5℃ to 80℃ (dynamic)
- Surface treatment: Electropolished interior, satin exterior
- Seal type: Double O-ring (FKM/Viton® optional)
- Panel thickness compatibility: 1-10mm
- Weight: 28g ±1g
- Dimensions: 32mm(Total L) × 18mm(Hex width) × 14mm(Panel nut Ø)
- Flow coefficient (Cv): 0.25
- Leakage rate: ≤3 bubbles/min (ISO 6952-1)
- Vibration resistance: 10-2000Hz, 20G acceleration
Heavy-duty bulkhead connector featuring corrosion-resistant stainless construction and dual sealing system. The through-panel design enables secure fluid path transitions between compartments while maintaining panel integrity. Precision-machined PTFE composite bushings prevent metal-to-metal contact during thermal expansion.
- High-cycle pneumatic tool changers
- Semiconductor vacuum chamber feedthroughs
- Hydraulic power unit manifold interfaces
- Steam sterilization equipment plumbing
- Mobile hydraulic cylinder port connections
Installation protocol:
Apply thread sealant only on male threads (not required for BSPP).
Torque to 12-15 N·m using backup wrench on hex flats.
Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | BPMF802 |
