Airtac BSAID Clamp Cylinder BSAID100X450
The AirTAC Airtac BSAID Clamp Cylinder BSAID100X450 is a genuine double-acting ISO 15552 cylinder with a Ø100mm bore, 450mm stroke and a spring-applied, air-released clamp-lock that holds the rod at ANY position along its travel — with a static holding force of 5500 N.
- BoreØ100 mm
- Stroke450 mm
- Cylinder portG1/2
- TypeDouble rod (BSAID)
- Enclasp portG1/8
- Rod threadM20×1.5
About the Airtac BSAID Clamp Cylinder BSAID100X450
The AirTAC BSAID100X450 is a double-acting ISO 15552 profile cylinder featuring a double-rod design and an integrated spring-applied, air-released clamp-lock. It provides a static holding force of 5500 N and locks the load at any position along its 450 mm stroke. Because it is a double-rod unit, it delivers equal thrust in both directions (3681 N at 0.5 MPa), and having a rod extending from each end allows you to mount a workpiece on one side and a guide or position flag on the other for dual-side anti-rotation.
It is vital to distinguish holding force from thrust: the 5500 N clamp grip is a separate static metric from the 3681 N pneumatic thrust, meaning you must size the clamp against your static load, not the cylinder's push force. The clamp engages only after the piston has stopped, meaning it cannot brake a moving rod. Furthermore, the lock releases only when air pressures on both sides are balanced via the G1/8 enclasp port; otherwise, the rod may jump abruptly upon release.
Airtac BSAID Clamp Cylinder BSAID100X450 Technical Specifications
| Model | Airtac BSAID Clamp Cylinder BSAID100X450 |
|---|---|
| Series | BSAI ISO 15552 clamp-lock cylinder |
| Bore size | Ø100 mm |
| Stroke | 450 mm |
| Type | Double rod (BSAID), double acting |
| Cylinder port | G1/2 |
| Rod thread | M20×1.5 |
| Lock type | Spring-applied, air-released clamp (any position) |
|---|---|
| Static holding force | 5500 N |
| Enclasp / unlock port | G1/8 |
| Operating pressure | 0.15 – 0.7 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC BSAI datasheet (ISO 15552). Operating pressure is 0.15–0.7 MPa (lower than a plain SAI). Port options: PT / G.
How the Clamp-Lock Holds
static holding force (Ø100 mm)
A spring-applied gripper clamps the rod and holds the load at any position in the stroke — not just at the stroke end (that is a SAIL) — and it is bidirectional: it holds whether the rod was extending or retracting.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa (max) | 5498 N | — |
Equal force both directions (double rod). Rated to the 0.7 MPa operating maximum for this series. The clamp holding force (5500 N) is separate from cylinder thrust. Size with a margin.
Where the Airtac BSAID Clamp Cylinder BSAID100X450 Is Used
Vertical Lift Holding
Secures heavy vertical loads at any point in the 450 mm travel, preventing sudden drops when air pressure is removed.
Machining Position Lock
Holds a dual-sided workpiece rigidly for machining or inspection, using the second rod for a counterweight or guide.
Power Failure Safety
The spring-applied clamp engages automatically upon loss of air pressure, freezing the load safely mid-stroke.
Is the Airtac BSAID Clamp Cylinder BSAID100X450 the Right Clamp-Lock?
Choose this 100 mm bore model when an application demands high bidirectional force and mid-stroke holding, such as heavy vertical lifting. If your load is lighter, stepping down to an 80 mm bore offers 2268 N of pull thrust and a 3600 N holding force. Conversely, a 125 mm bore provides 5734 N pull thrust and 8600 N holding force for heavier rigs. This BSAID100X450 outperforms a SAIL cylinder because it locks anywhere, whereas SAIL only holds at stroke ends; a plain SAID suffices if no intermediate holding is required.
As a replacement, match the double-rod configuration, 100 mm bore, 450 mm stroke, and PT-threaded ports (1/2 inch cylinder ports plus the G1/8 enclasp port). The BSAID mounting set omits FB, CA, CB, and CR brackets, accepting only Basic, FA, LB, TC, TCM1, and TCM2. Because the 450 mm stroke exceeds 300 mm, an external guide is recommended to prevent rod side-loading, even with the sturdy 25 mm rod and M20x1.5 thread. No magnet is specified, so CMSE/DMSE sensors will not function without modification.
Quick checklist
- ✓ Hold needed at any position?
- ✓ Or stroke-end only → use SAIL
- ✓ Holding force ≥ your load
- ✓ Balanced-pressure unlock circuit
- ✓ Extra safety measure for people
Airtac BSAID Clamp Cylinder BSAID100X450 FAQ
The integrated clamp-lock provides a static holding force of 5500 N. It engages only after the cylinder has stopped moving and holds the load at any position along the stroke.
The lock is released by supplying air to the G1/8 enclasp port only after the pressures on both sides of the piston are balanced. If pressures are unbalanced, the rod can jump abruptly upon release.
