Airtac BSC Clamp Cylinder BSC50X1000
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X1000 Technical Details
- Model: BSC50X1000
- Type: Double-acting clamp cylinder (ISO 15552 standard)
- Bore size: Ø50 mm (±0.1mm manufacturing tolerance)
- Stroke: 1000 mm (adjustable cushioning)
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)/-10℃ to 70℃ (Polyurethane seals)
- Cushioning type: Adjustable hydraulic shock absorber (both ends)
- Mounting style: Basic type (optional flange/clevis/foot mounts)
- Port size: G1/8 (BSPP thread) with 6mm push-in fittings
- Piston rod thread: M16×1.5 (external)
- Material: Aluminum alloy barrel, chrome-plated steel rod
- Weight: 6.8 kg (±3% production variance)
- Dimensions:
- Extended length: 1285 mm
- Retracted length: 285 mm
- Body diameter: Ø60 mm
- Max thrust: 785N @ 0.63MPa (90% load efficiency)
- Speed range: 50-750 mm/s (lubricated operation)
- Protection rating: IP54 (standard wiper seal)
Heavy-duty clamp cylinder engineered for precision gripping applications requiring extended stroke stability. Features wear-resistant chromium rod coating and dual anti-rotation guides (patented design) to prevent piston spin during long-stroke operation. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automotive welding fixture positioning systems
- Die-casting machine mold clamping
- Sheet metal bending press tooling
- Paper roll handling in printing facilities
- CNC machine workpiece securing
Installation protocol:
Mount with 0.05mm/m alignment tolerance maximum. Use flexible couplings for
stroke lengths >800mm. Perform weekly lubrication checks during initial 200hr
break-in period. Requires 40μm filtration for compressed air supply.
| Property | Property Value |
|---|---|
| sku | BSC50X1000 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <1000mm> |
| Static Holding Force | 900N |
