Airtac BSC Clamp Cylinder BSC50X1000S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X1000S Technical Details
- Model: BSC50X1000S
- Bore size: Ø50 mm
- Stroke: 1000 mm
- Operating pressure: 0.05-1.0 MPa
- Action type: Double-acting
- Cushioning: Adjustable hydraulic buffer (both ends)
- Mounting style: Standard MF1 (front flange) with optional rear flange
- Port size: G1/2 (ISO228/1 standard)
- Piston rod material: SCM435 steel with hard chrome plating (25μm)
- Tube material: Aluminum alloy (Al6063-T5) with hard anodizing
- Seals: NBR (standard) / PU (optional for high-speed applications)
- Operating temperature: -20℃ to 80℃ (NBR seals)
- Weight: 12.8 kg (dry, without accessories)
- Dimensions:
- Extended length: 1,280 mm
- Retracted length: 280 mm
- Body diameter: 63 mm
- Mounting hole spacing: 90×90 mm (MF1 pattern)
- Max theoretical thrust: 1,963N @0.63MPa
- Lubrication: Pre-lubricated (Grease-free operation possible)
- ISO certification: 6431, 15552 compliant
High-rigidity clamp cylinder engineered for heavy-duty positioning and pressing applications. Features dual chrome-plated guide rods (Ø16mm) for enhanced lateral stability and anti-rotation performance. The extended stroke design incorporates a reinforced piston rod (surface hardness HRC45-50) to prevent deflection during full extension.
- Automotive welding fixture clamping systems
- Die-casting machine mold locking mechanisms
- Large-format CNC router material hold-down
- Paper roll tensioning in printing presses
- Solar panel lamination press alignment
Installation guidelines:
Requires horizontal mounting for optimal performance. Use alignment jigs during installation to ensure parallel guide rod movement. For strokes >800mm, recommend adding intermediate support brackets (ASF-50 accessory). Lubricate rod ends with ISO VG32 hydraulic oil monthly in continuous operation.
| Property | Property Value |
|---|---|
| sku | BSC50X1000S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <1000mm> |
| Static Holding Force | 900N |
